140

Spareparts MASTER MANUAL GAS HEATERS 15 kW Reg.

Pos. Code NR Description

1 4160.714 OUTLET GRID

2 4161.372 COMBUSTION CHAMBER

3 4160.921 YELLOW COVER RAL 1006

4 4160.715 PLASTIC HANDLE

5 4160.689 FAN Ø172 19°

6 4160.628 ELECTRIC MOTOR 29 W 230/50-60HZ IP44

7 4160.713 PLASTIC GRID

8 4160.636 SAFETY THERMOSTAT 90°

9 4160.708 SUPPORT FOR THERMOSTAT

10 4160.707 IGNITION ELETTRICAL FOLDER

11 4160.654 INTERRUPTED THERMOCOUPLE

12 4160.746 GAS NOZZLE

13 4160.742 EXTENSION

14 4160.675 COCK

15 4160.655 ELECTRO VALVE

16 4160.653 SAFETY GAS VALVE

17 4160.701 RING NUT M12X0,75ER

18 4160.700 GAS INLET NOZZLE 3/8 M - 1/8 M

19 4160.635 KEEPER WIRE DEVICE

20 4160.733 ELECTRIC CABLE

21 4160.638 COVER SWITCH

22 4160.637 SWITCH

23 4160.641 PIEZO IGNITOR

24 4160.640 ADAPTER FOR PIEZO IGNITOR

25 4160.760 PLASTIC BASE

26 4160.620 90° DEGREE ELBOW 1/8"

27 4160.702 GAS BURNER

28 4160.627 ELASTIC WASHER
